Echo4x4 Echo 5 Thunder Off-Road Trailer

Quick Information Guide

Can Sleep

2/3People

Dimensions

(L)3900mm x
(W)1850mm x
(H)1600mm

Tare

595kg - 1800kg GVM

Braked Axle

Independent suspension braked axle. Optional 32" Blade spring solid braked axle

Tyres

15" Steel rims (Std)

Water Tank

125L water tank Charcoal

Jerry Cans

0

All Features and Optimal Extras

• LP Gas cylinder storage trays (x2)

• 125L Water tank

• Front and rear 4-drawer modular system

• 4 Drawer modular system

• Jerry-can mounting brackets (x2) (jerry-cans OPTIONAL) Thunder grey

• Tec nose-cone with fridge slider

• Wood rack above nose-cone

• 1.2mm Electro galvanised steel

• Stainless steel bolts and nuts

• Container style doors

• Automotive style door rubbers

• Galvanised

• Ratchet lift rear support struts

• Skid plate on A-frame

• High lift jack points

• 15” Steel rims (standard) • Add-on room to tent

• 2500kg Rated axle • Full side wall set

• Independent suspension (2500kg rated) • Ground sheets

• Shock absorbers • Condensation sheets

• Rear mounted spare wheel • Stone-net protector

• 200mm Heavy duty removable jockey-wheel • Bed extension and mattresses

• Break-away cable • Full PVC cover

• 38” 8 Blade suspension with floating shackle

• Wash basin and drying rack

• Self igniting glass top LP gas hobb

• Trailer tent with drop down / side room

• High density foam mattress

• 400g Military spec two tone canvas

• Rip-stop canvas

• Condensation sheet/s

• 12V / 24V LED Truck type lights

• 12V / 24V LED Number plate light• 7 Pin standard wiring (SABS)

• EPP3-7 MK2—20A—power management system—fitted with high cycle battery

• 12V High pressure water pump

• 105Ah High cycle battery

• Slide out bathroom with shower
• Flexible hand held shower
• Solid moulded shower floor
• Soap rack, mirror and shower curtain
OPTIONAL EXTRAS
• Porta Potti
• Aircon
• Silent Generator
• Solar panel and mounting
• 220 Volt Extension cable 20m
• 220 Volt Caravan adaptor
• Side walls
• Ground sheets

• Silent generator

• 40-90L fridge / freezer (National Luna spec)

• Non-standard Echo rims / tyres

• 220V Caravan adaptor

• Add-on room to tent

• Full side wall set

• Ground sheets

• Condensation sheets

• Stone-net protector

• Bed extension and mattresses

• Break-away cable • Full PVC cover

• Spare wheel cover

• Mud flaps

• Fire extinguisher

• Stove windshield

Independent coil spring

COLOUR OPTIONS: Legend Light grey , Tech dark grey ,

• Tare: 595kg

• GVM: 1800kg

• Dimensions: W x L x H

• Load-body: W x L x H:  1500mm x 2200 x 910

• Load-body volume: 3003L

• Nose-cone volume: 393L
